Meitrack MVT100
		Magnetic GPS Tracker for Motorcycle
		The MVT100 is a vehicle tracker that can be used for cars, motorcycles, yachts, and boats. The MVT100’s unique design makes its appearance cool. The product is easy to install, water resistant (IP66), dustproof, and has built-in antenna.
		Download MVT100 Flyer>> Download MVT100 CD>>



FEATURES



		IP66 water resistant Specialized design guarantees a stable operating performance.				Unique design Special design enables it blend into most motorcycles and boats.
		Anti-theft An alarm along with the remote fuel/ power cut-off feature can protect your vehicle from theft.				Multiple alarms Support SOS/low power/towing/speeding/geo-fence alarms.



APPLICATIONS

SPECIFICATIONS



	Dimension		110 mm x 72 mm x 39 mm		Weight		170g
	Input voltage		DC 11 V to 36 V/1.5 A		Backup battery		400 mAh/3.7 V
	Power consumption		Current in standby mode: 65 mA		Operating temperature		-20°C to 55°C
	Operating humidity		5% to 95%		Working hour		80 hours in power-saving mode and 5.7 hours in normal mode
	LED indicator		2 indicators showing GSM and GPS status		Button/Switch		1 SOS button (for sending SMSs)1 power button (next to the SIM card slot)
	Memory		8 MB buffer		Sensor		3-axis accelerometer (used to wake the device up by vibration and detect towing alarms)
	Frequency band		GSM 850/900/1800/1900 MHz		GPS sensitivity		-161 dB
	Positioning accuracy		2.5m		Antenna		Built-in GSM and GPS antennas
	I/O port		2 inputs (1 negative input and 1 positive input) 1 analog detection input1 output1 USB port

ACCESSORIES



	MVT100 with a built a battery, I/O cable, and SOS button		3M sticker		Screws
			USB cable		CD download card



CERTIFICATES
